2.0mm Pitch SMT Pogo Pin Connector china supplier,Custom high current pogo connector,Pogo pin manufacturers,high current Pogo pin(5A-30A),Products life reach 1000,000 cycles,Pogo pin connector-CFE
Customized service
| Part NO. | A | B | C | D | E | F | Stroke(mm) | Force(g) | Current(A) | |
|---|---|---|---|---|---|---|---|---|---|---|
| BF00111 | 4.30 | 3.30 | 0.50 | 1.80 | 1.50 | 0.90 | 1.0 | 50 | 1 |  |
| BF00217 | 15.20 | 13.70 | 0.60 | 1.63 | 1.50 | 0.90 | 0.9 | 100 | 1 | |
| BF00218 | 15.20 | 13.70 | 0.63 | 1.63 | 1.50 | 0.90 | 0.9 | 100 | 1 | |
| BF00261 | 16.50 | 15.00 | 0.60 | 1.55 | 1.45 | 0.90 | 0.9 | 100 | 1 | |
| BF00511 | 4.00 | 2.50 | 0.50 | / | 1.50 | 0.90 | / | 120 | 1 | |
| BF00611 | 3.00 | 2.00 | 0.50 | 2.00 | 1.50 | 0.90 | 0.7 | 50 | 1 | |
| BF00811 | 5.50 | 4.50 | 0.50 | 1.80 | 1.48 | 0.90 | 0.8 | 120 | 1 | |
| BF01011 | 4.20 | 3.20 | / | / | 1.00 | 0.50 | 0.8 | 40 | 1 | |
| BF01211 | 17.00 | 14.70 | 2.00 | 1.70 | 2.00 | 1.40 | 1.5 | 130 | 2 | |
| BF01311 | 9.00 | 6.50 | 3.30 | 1.50 | 1.60 | 1.10 | 80 | |
||
| BF01411 | 3.50 | 2.50 | 0.40 | 1.82 | 1.76 | 1.06 | 0.5 | 60 | 1 | |
| BF01811 | 3.00 | 2.00 | 0.40 | 1.83 | 1.55 | 1.05 | 0.7 | 110 | 1 | |
| BF01911 | 4.40 | 3.40 | 0.40 | 1.83 | 1.55 | 1.07 | 0.6 | 150 | 1 | |
| BF02011 | 6.00 | 4.00 | 0.50 | 2.00 | 1.50 | 0.90 | / | 80 | 1 | |
| BF02014 | 6.00 | 4.00 | 0.50 | 2.00 | 1.50 | 1.00 | 1.0 | 80 | 1 | |
| BF02211 | 8.00 | 5.50 | 0.70 | 1.80 | 1.60 | 1.00 | 1.5 | 130 | 2 | |
| BF02811 | 16.50 | 13.00 | / | / | 2.00 | 1.40 | 1.5 | 150 | 1 | |
| BF03024 | 7.00 | 4.50 | / | / | 2.95 | 2.30 | 1.5 | 180 | / | |
| BF03111 | 9.00 | 6.50 | 3.30 | 1.35 | 1.45 | 0.90 | 1.5 | 80 | / | |
| BF03511 | 5.40 | 3.90 | 0.70 | 1.80 | 1.50 | 1.00 | 1.0 | 120 | 3 | |
| BF04312 | 12.60 | 11.10 | 0.90 | 1.80 | 1.50 | 0.90 | 1.0 | 60 | 1 | |
| BF04320 | 20.60 | 19.10 | 0.90 | 1.80 | 1.50 | 0.90 | 1.0 | 30 | 1 | |
| BF04336 | 36.60 | 35.10 | 0.90 | 1.80 | 1.50 | 0.90 | 1.0 | 60 | 1 | |
| BF04511 | 6.82 | 5.42 | 0.60 | 1.90 | 1.50 | 0.90 | 0.9 | 100 | 1 | |
| BF04711 | 5.00 | 3.60 | 0.50 | 1.80 | 1.50 | 1.00 | / | 110 | 1 | |
| BF04811 | 7.00 | 5.00 | 0.50 | 1.80 | 1.50 | 1.00 | 0.7 | 50 | 2 | |
| BF04911 | 2.30 | 1.60 | 0.40 | 1.45 | 1.35 | 0.90 | / | 70 | 1 | |
| BF05211 | 7.90 | 5.70 | 0.60 | 1.80 | 1.50 | 0.90 | 1.2 | 60 | 2 | |
| BF05711 | 5.50 | 3.05 | 0.50 | 2.30 | 1.50 | 1.00 | 0.9 | 45 | 1 | |
| BF05721 | 4.50 | 2.45 | 0.50 | 2.30 | 1.50 | 1.00 | 0.5 | 45 | 1 | |
| BF05811 | 14.00 | 9.00 | / | / | 1.50 | 1.00 | / | 120 | 1 | |
| BF06311 | 4.00 | 2.70 | 0.40 | 2.50 | 1.50 | 0.90 | 1.0 | 80 | 1 | |
| BF06911 | 7.30 | 5.25 | 0.50 | 1.36 | 1.30 | 0.80 | 0.8 | 95 | 2 | |
| BF08211 | 2.90 | 1.70 | 0.40 | 2.00 | 1.50 | 0.90 | 0.9 | 65-95 | 1 | |
| BF08311 | 2.30 | 1.50 | 0.30 | 1.40 | 1.25 | 0.80 | / | 30 | 1 | |
| BF08312 | 2.30 | 1.50 | 0.30 | 1.40 | 1.25 | 0.80 | / | 30 | 1 | |
| BF08511 | 3.60 | 2.30 | 0.30 | 2.00 | 1.25 | 0.80 | / | 70 | 1 | |
| BF08811 | 3.50 | 2.50 | 0.30 | 1.70 | 1.50 | 0.90 | 0.5 | 45 | 1 | |
| BF09511 | 4.50 | 2.45 | 0.40 | 2.30 | 1.50 | 1.00 | / | 45 | 1 | |
| BF09611 | 4.25 | 3.25 | 0.50 | 3.50 | 2.50 | 2.00 | 1.0 | 300 | 1 | |
| BF09612 | 4.25 | 3.25 | / | 3.50 | 2.50 | 2.00 | 1.0 | 300 | 1 | |
| BF09711 | 3.20 | 2.00 | / | 2.00 | 1.25 | 0.80 | / | 95 | 1 | |
| BF09811 | 6.00 | 4.50 | / | 1.80 | 1.35 | 0.85 | 0.5 | 25-45 | 1 | |
| BF09812 | 6.00 | 4.50 | 1.00 | 1.80 | 1.35 | 0.85 | 1.0 | 110 | 1 | |
| BF10001 | 5.00 | 3.30 | 1.00 | 1.80 | 1.48 | 1.00 | 1.0 | 30 | 1 | |
| BF10411 | 3.40 | 2.50 | 0.40 | 1.80 | 1.50 | 1.00 | 0.8 | 110 | 1 | |
| BF10412 | 3.40 | 2.50 | 0.40 | 1.80 | 1.50 | 1.00 | 0.6 | 60 | 1 | |
| BF10413 | 3.40 | 2.50 | 0.40 | 1.80 | 1.50 | 1.00 | 0.8 | 110 | 3 | |
| BF10511 | 4.00 | 3.00 | 0.40 | 1.80 | 1.48 | 1.00 | / | 60 | 3 | |
| BF10711 | 3.70 | 2.40 | 0.40 | 1.80 | 1.48 | 1.00 | 0.7 | 110 | 1 | |
| BF11611 | 4.70 | 4.00 | 0.25 | 1.88 | 1.57 | 1.00 | 0.7 | 88 | 3 | |
| BF12711 | 4.30 | 3.00 | / | / | 1.50 | 0.90 | 0.8 | 100 | 2 | |
| BF12821 | 9.50 | 7.00 | 1.50 | 2.00 | 1.48 | 0.90 | 1.0 | 125 | 2 | |
| BF13601 | 9.40 | 8.30 | / | 1.80 | 1.48 | 1.00 | 1.0 | 70 | 3 | |
| BF13611 | 9.90 | 8.30 | / | 1.80 | 1.48 | 1.00 | 1.0 | 70 | 3 | |
| BF13621 | 10.40 | 8.30 | / | 1.80 | 1.48 | 1.00 | 1.0 | 70 | 3 | |
| BF14611 | 6.50 | 3.50 | 0.40 | 2.00 | 1.50 | 1.00 | 2.0 | 60 | 1 | |
| BF15001 | 7.00 | 4.50 | 2.50 | 3.50 | 2.90 | 2.30 | 1.5 | 180 | / | |
| BF15311 | 8.30 | 5.20 | 0.80 | 3.50 | 2.30 | 1.10 | 0.7 | 70 | 3 | |
| BF15711 | 10.50 | 4.50 | / | / | 1.50 | 0.90 | 1.0 | 100 | 1 | |
| BF15811 | 5.00 | 3.60 | 0.40 | 1.80 | 1.48 | 1.00 | 1.0 | 120 | 1 | |
| BF16511 | 2.50 | 1.90 | 0.70 | 1.80 | 1.60 | 1.00 | 1.9 | 50 | 0.5 | |
| BF16611 | 4.50 | 3.20 | 0.70 | 1.80 | 1.60 | 1.00 | 1.3 | 90 | 0.5 | |
| BF18311 | 2.10 | 1.45 | 0.55 | 1.30 | 1.05 | 0.70 | 1.7 | 6 | 1 | |
| BF19101 | 5.50 | 4.00 | 0.80 | 2.00 | 1.48 | 0.90 | 0.7 | 80 | 2 | |
| BF19401 | 2.54 | 1.90 | 0.40 | 1.80 | 1.48 | 1.00 | 0.5 | 50 | 1 | |
| BF19701 | 9.50 | 7.00 | / | / | 2.95 | 2.30 | 1.5 | 180 | 1 | |
| BF19801-02350H1A | 7.50 | 5.30 | 1.80 | 1.48 | 1.00 | 1.0 | 70 | 1 | |
|
| BF19901 | 11.00 | 8.00 | 0.40 | 1.80 | 1.50 | 1.00 | 1.0 | 90 | 2.5 | |
| BF20401 | 4.50 | 2.70 | 0.40 | 1.80 | 1.80 | 1.07 | 1.0 | 60 | 1 | |
| BF21801 | 6.40 | 4.60 | 1.00 | 2.50 | 2.00 | 1.50 | 1.0 | 150 | 4 | |
| BF25011 | 4.30 | 2.60 | / | 3.10 | 2.55 | 1.90 | 0.9 | 250 | 1 | |
| BF30611 | 7.10 | 4.50 | / | / | 3.50 | 2.70 | 2.6 | 200 | / | |
| BF31511 | 11.50 | 8.80 | 0.60 | 5.00 | 2.30 | 1.50 | 1.75 | 235 | 3 | |
| BF31911 | 23.60 | 15.70 | / | / | 2.00 | 1.40 | 4.0 | 250 | |
|
| BF36211 | 2.80 | 2.00 | / | 2.00 | 1.50 | 0.90 | 0.8 | 60 | 0.1 | |
| BF36621 | 4.00 | 2.50 | 0.40 | 2.00 | 1.50 | 1.00 | 1.0 | 40 | 1 | |
| BF36811 | 2.50 | 1.60 | 0.30 | 1.40 | 1.25 | 0.80 | 0.5 | 55 | 0.5 | |
| BF37111-10254H0A | 9.00 | 7.30 | 4.25 | / | / | 1.00 | 0.7 | 60 | 2 | |
| BF37211-06254B0A | 3.80 | / | 0.40 | 2.00 | / | 1.00 | 0.8 | 25 | 1 | |
| BF37311-08340H0A | 9.00 | / | / | / | 1.48 | 0.90 | 1.8 | 75 | 1 | |
| BF38411-04254F0A | 11.00 | 7.30 | 4.00 | 5.08 | / | 1.00 | 1 | 70 | 3 | |
| BF38511 | 2.40 | 1.45 | 0.30 | 1.80 | 1.48 | 0.90 | 1.8 | 120 | 1.5 | |
| BF38511-0325001A | 2.30 | 1.45 | 0.30 | 1.80 | 1.53 | 0.90 | 1.8 | 120 | 1.5 | |
| BF38522 | 2.50 | 1.70 | 0.40 | 1.80 | 1.48 | 1.00 | 0.6 | 100 | 1.0 | |
| BF39311-12254H0A | 6.50 | 3.00 | 0.40 | 1.80 | 1.50 | 1.00 | 1.8 | 60 | 1 | |
| BF39511 | 3.30 | 2.70 | 0.50 | 2.20 | 1.80 | 1.00 | 0.5 | 60 | 1 | |
| BF40511 | 5.00 | 3.50 | 0.80 | 1.60 | 1.20 | 0.70 | 1.1 | 90 | 1 | |
| BF40611-06254S0A | 7.62 | 5.08 | 2.54 | 1.27 | / | / | 0.62 | 50 | 1 | |
| BF40711-01000H1A | 3.90 | 3.00 | 2.60 | 1.80 | 1.50 | 1.00 | 0.8 | 40 | 1 | |
| BF40911 | 3.50 | 2.50 | / | 1.80 | 1.48 | 1.00 | 0.5 | 60 | 1 | |
| BF42011-02762E0A | 7.30 | 4.00 | 0.4 | / | 2.54 | 1.00 | 1 | 70 | 1 | |
| BF42411 | 11.50 | 2.00 | 0.50 | 4.00 | 3.50 | 3.00 | 0.8 | 100 | / | |
| BF44511 | 5.00 | 3.70 | 0.40 | 2.00 | 1.50 | 0.90 | 1.0 | 50 | 1.0 | |
| BF44711-A03113A | 8.00 | 5.30 | / | / | / | 1.00 | 1 | 30 | 1 | |
| BF44911-05250H0A | 7.50 | 0.40 | 1.80 | / | 1.00 | / | 1 | 70 | 3 | |
| BF45111 | 2.00 | 1.55 | 0.40 | 2.10 | 1.78 | 1.20 | 0.4 | 70 | 1.0 | |
| BF46911 | 4.00 | 2.60 | 0.40 | 1.80 | 1.48 | 1.00 | 0.8 | 100 | 1 | |
| BF47011 | 3.90 | 2.70 | / | / | 1.60 | 1.00 | 0.6 | 50 | 1 | |
| BF47111 | 3.10 | 2.20 | / | 1.80 | 1.30 | 0.90 | 0.6 | 70 | 1 | |
| BF47711 | 4.90 | 3.50 | / | 2.00 | 1.48 | 1.00 | 0.8 | 80 | 1 | |
| BF47911 | 9.50 | 8.00 | 0.40 | 1.90 | 1.48 | 1.00 | 0.8 | 60 | 1 | |
| BF12891 | 9.50 | 7.00 | 1.70 | 1.80 | 1.48 | 1.00 | 1.0 | 125 | 2 | |
| BF49811 | 4.80 | 3.50 | 0.50 | 1.80 | 1.50 | 0.90 | 0.0 | 40 | 2 | |
| BF57811 | 5.50 | 4.00 | 0.50 | 2.00 | 1.50 | 1.00 | 1.00 | 100.00 | 3 | |
| BF56111 | 5.30 | 4.00 | / | / | 3.00 | 2.20 | 1.00 | 100.00 | 1 | |
| BF60511 | 5.00 | 3.30 | 0.40 | 1.80 | 1.48 | 1.00 | 0.6 | 30 | 1 | |
| MF801-11GG | 1.30 | 1.00 | 0.40 | 1.50 | 1.28 | 0.80 | 0.2 | 20 | 1 | |
| MF802-11GG | 1.50 | 1.30 | 0.40 | 1.50 | 1.28 | 0.80 | 0.2 | 20 | 1 | |
| MF802-21GG | 1.70 | 1.30 | 0.40 | 1.50 | 1.28 | 0.80 | 0.2 | 20 | 1 | |
| MF803-11GG | 1.90 | 1.50 | 0.40 | 1.50 | 1.28 | 0.80 | 0.4 | 70 | 1 | |
| MF803-21GG | 2.10 | 1.50 | 0.40 | 1.50 | 1.28 | 0.80 | 0.4 | 70 | 1 | |
| MF803-31GG | 2.30 | 1.50 | 0.40 | 1.50 | 1.28 | 0.80 | 0.4 | 70 | 1 | |
| MF804-11GG | 2.50 | 1.70 | 0.40 | 1.50 | 1.28 | 0.80 | 0.6 | 70 | 1 | |
| MF804-21GG | 2.70 | 1.70 | 0.40 | 1.50 | 1.28 | 0.80 | 0.6 | 70 | 1 | |
| MF805-11GG | 2.90 | 2.00 | 0.40 | 1.50 | 1.28 | 0.80 | 0.6 | 80 | 1 | |
| MF806-11GG | 3.10 | 2.30 | 0.40 | 1.50 | 1.28 | 0.80 | 0.8 | 80 | 1 | |
| MF806-21GG | 3.30 | 2.3 | 0.40 | 1.50 | 1.28 | 0.80 | 0.8 | 80 | 1 | |
| MF807-11GG | 3.50 | 2.60 | 0.40 | 1.50 | 1.28 | 0.80 | 0.8 | 80 | 1 | |
| MF807-21GG | 3.70 | 2.60 | 0.40 | 1.50 | 1.28 | 0.80 | 0.8 | 80 | 1 | |
| MF807-31GG | 4.00 | 2.60 | 0.40 | 1.50 | 1.28 | 0.80 | 0.8 | 80 | 1 | |
| MF808-11GG | 4.20 | 3.00 | 0.40 | 1.50 | 1.28 | 0.80 | 1.0 | 80 | 1 | |
| MF808-21GG | 4.40 | 3.00 | 0.40 | 1.50 | 1.28 | 0.80 | 1.0 | 80 | 1 | |
| MF809-11GG | 4.50 | 3.30 | 0.40 | 1.50 | 1.28 | 0.80 | 1.0 | 70 | 1 | |
| MF809-21GG | 5.00 | 3.30 | 0.40 | 1.50 | 1.28 | 0.80 | 1.0 | 70 | 1 | |
| MF810-11GG | 5.50 | 4.30 | 0.40 | 1.50 | 1.28 | 1.00 | 1.0 | 70 | 1 | |
| MF810-21GG | 6.00 | 4.30 | 0.40 | 1.50 | 1.28 | 1.00 | 1.0 | 70 | 1 | |
| MF811-11GG | 6.50 | 5.30 | 0.40 | 1.50 | 1.28 | 0.80 | 1.0 | 70 | 1 | |
| MF811-21GG | 7.00 | 5.30 | 0.40 | 1.50 | 1.28 | 0.80 | 1.0 | 70 | 1 | |
| MF811-31GG | 7.50 | 5.30 | 0.40 | 1.50 | 1.28 | 0.80 | 1.0 | 70 | 1 | |
| MF811-41GG | 8.00 | 5.30 | 0.40 | 1.50 | 1.25 | 0.80 | 1.0 | 70 | 1 | |
| BF65111 | 8.20 | 6.00 | 0.50 | 2.30 | 2.00 | 1.50 | 7.2 | 120 | 2 | |
| BF65511 | 3.50 | 2.70 | 0.50 | 2.00 | 1.50 | 0.90 | 0.5 | 70 | 1 | |
| BF65711 | 2.00 | 1.00 | / | / | 1.22 | 0.80 | 0.7 | 60 | 1 | |
| BF69011 | 2.95 | 1.85 | 0.30 | 2.00 | 1.25 | 0.80 | 2.5 | 40 | 1 | |
| BF72411 | 2.70 | 1.70 | 0.40 | 1.70 | 1.38 | 0.90 | 0.6 | 100 | 1 | |
| BF76611 | 3.25 | 2.00 | 0.30 | 1.80 | 1.48 | 0.90 | 0.7 | 50 | 1 | |
| BF68611 | 7.25 | 6.15 | 0.67 | 1.80 | 1.48 | 1.00 | 1.0 | 70 | 3 | |
| BF67111 | 6.30 | 4.90 | 0.30 | 1.30 | 1.08 | 0.65 | 1.3 | 60 | 1 | |
| BF67121 | 6.00 | 4.90 | 0.30 | 1.30 | 1.08 | 0.65 | 1.0 | 50 | 1 | |
| BF80211 | 5.00 | 3.50 | 0.30 | 1.00 | 0.90 | 0.50 | 0.5 | 40 | 1 | |
| BF83911 | 11.50 | 10.00 | 0.40 | 1.80 | 1.48 | 1.00 | 0.7 | 85 | 3 | |
| BF60721 | 8.10 | 6.80 | 0.40 | 1.20 | 1.02 | 0.60 | 1.0 | 40 | 1 | |
| BF60731 | 8.10 | 6.80 | 0.40 | 1.20 | 1.02 | 0.60 | 1.0 | 30 | 1 | |
| BF86211 | 3.30 | 2.50 | / | / | 1.00 | 0.45 | 0.6 | 60 | 1 | |
| BF89711 | 2.90 | 2.20 | 0.40 | 1.80 | 1.48 | 1.00 | 0.9 | 80 | 1 | |
| BF89721 | 3.70 | 2.70 | 0.40 | 1.80 | 1.48 | 1.00 | 0.6 | 80 | 1 | |
| BF82111 | 6.00 | 4.30 | 0.40 | 1.80 | 1.48 | 1.00 | 1.0 | 50 | 2 | |
| BF91901 | 3.50 | 2.60 | 0.30 | 2.50 | 1.50 | 1.00 | 0.6 | 70 | 1 | |
| BF16611 | 4.50 | 3.20 | 0.70 | 1.80 | 1.60 | 1.00 | 3.50 | 75 | 0.5 | |
| BF98111 | 4.80 | 3.30 | 0.60 | 1.45 | 1.20 | 0.70 | 4.00 | 60 | 1 | |
| BF95711 | 11.20 | 8.20 | 1.00 | 4.50 | 3.20 | 2.00 | 1.00 | 90 | 3 | |
| BF25011 | 2.60 | 4.20 | / | 3.10 | 2.55 | 1.90 | 3.30 | 250 | 1 | |
| BF80211 | 3.50 | 5.00 | 0.80 | 1.00 | 0.90 | 0.50 | 0.50 | 40 | 1 | |
| BF76811 | 6.05 | 3.40 | 2.65 | 8.20 | 7.00 | / | 2.50 | 30 | ||
| BF79411 | 8.00 | 6.00 | 0.50 | 2.50 | 2.00 | 1.20 | 1.50 | 120 | 3 | |
| BF106301 | 3.50 | 2.60 | 0.40 | 1.80 | 1.48 | 1.00 | 0.80 | 100 | 1 |
Learn more about How to order special pogo pin, If you have special requirements please contact us
You may like Standard SMT Pogo Pin Spec from CFE
About us
CFE is the leader of the pogo pin industry in China. The philosophy of our firm is : quality is the most important factor in business! Our company has established, maintained and relentlessly improved the quality management system, so as to ensure the highest quality of products and services.
During the pogo pin reliability test, the product undergoes several inspection procedures, including the dynamic impedance, constant temperature and pressure, durability, temperature increase, vibration, drop test and the instant-off test, etc. This ensures your client’s product will not break down due to a pogo pin defect.
Featured products
 |
 |
 |
 |
 |
 |
|||||
| SMT/SMD | DIP | Right angle | Double head | Solder cup | Screw thread |
Customization of pogo pin
In terms of customization, please provide your drawings or detailed requirements to our engineers. We can customized products based on your needs.
